Research on Designing the Continuously Variable Transmission Test Bench
Corressponding author's email:
tungdt@hcmute.edu.vnDOI:
https://doi.org/10.54644/jte.79.2023.1443Keywords:
Continuously Variable Transmission (CVT), Transmission Efficiency, Push Belt, Slip Ratio, Fuel ConsumptionAbstract
The continuously variable transmission (CVT) is designed to enhance the performance of the powertrain system. It helps the vehicle have better acceleration as well as improves the fuel economy. Fuel consumption in a car is directly linked to transmission efficiency, primarily influenced by the vehicle's drivetrain system. Factors affecting the transmission efficiency of transmission including belt structure, hydraulic pressure, and control technique are factors that need to be studied and improved. This study was carried out to calculate and design the mechanical, hydraulic, and electrical control systems of a CVT test bench. With the initially designed test bench simulated, it is possible to evaluate the characteristic quantities controlling the transmission ratio of the gearbox such as the pressure acting on the pulleys, the force acting on the belt, the torque at axes corresponding to different load modes vary from 2kW to 6 kW. The results of this study will be the basis for manufacturing an experimental system for in-depth studies and evaluation of the CVT such as belt slip, as well as the factors affecting transmission efficiency of CVT.
Downloads: 0
References
P. K. Wong, Z. Xie, and Y. Chen, "An Experimental Study on Dynamics of a Novel Dual-Belt Continuous Variable Transmission Based on a Newly Developed Test Rig," Hindawi Publishing Corporation Shock and Vibration, vol. 2015, Art no. 857978.
F. Bottiglione and G. Mantriota, "Effect of the Ratio Spread of CVU in Automotive Kinetic Energy Recovery Systems," Transactions of the ASME—Journal of Mechanical Design, vol. 135, no. 6, 2013, Art no. 061001.
G. Carbone, L. Mangialardi, and G. Mantriota, "Theoretical Model of Metal V-Belt Drives During Rapid Ratio Changing," Journal of Mechanical Design, vol. 123, no. 1, pp. 111–117, 2001.
G. Carbone, L. Mangialardi, and G. Mantriota, "The Influence of Pulley Deformations on the Shifting Mechanism of Metal Belt CVT," Journal of Mechanical Design, vol. 127, no. 1, pp. 103–113, 2005.
G. Carbone, L. Mangialardi, B. Bonsen, C. Tursi, and P. A. Veenhuizen, "CVT Dynamics: Theory and Experiments," Mechanism and Machine Theory, vol. 42, no. 4, pp. 409–428, 2007.
N. Srivastava and I. Haque, "A Review on Belt and Chain Continuously Variable Transmissions (CVT): Dynamics and Control," Mechanism and Machine Theory, vol. 44, no. 1, pp. 19–41, 2009.
A. Yildiz, F. Bottiglione, A. Piccininni, O. Kopmaz, and G. Carbone, "Experimental Validation of the Carbone–Mangialardi–Mantriota Model of Continuously Variable Transmissions," Proceedings of the Institution of Mechanical Engineers, Part D: Journal of Automobile Engineering, vol. 232, no. 6, pp. 828-837, 2018.
Z. Guo, D. Sun, L. Xu, and R. Xu, "Research on Continuous Power Shift Process of Hydro-Mechanical Continuously Variable Transmission," IOP Conf. Series: Materials Science and Engineering, vol. 790, p. 012172, 2020.
Guide Manual TB150, Bosch, 2022.
