Surveying the flat circuits at high frequencies with FWM and FDTD
Corressponding author's email:
sonpn@hcmute.edu.vnKeywords:
Microstrip line, FDTD, cavity model, full wave modelAbstract
There are various ways to survey the flat circuits at high frequencies. The most popular models are Microstrip Line Model (MLM), Cavity Model (CM) and Full-Wave Model (FWM). Among the above mentioned models, MLM is the least accurate model and unable to use for complex flat models. The CM is more accurate, and also more complex than the MLM. Yet, this model is well fit to the twin antenna with the good results. FWM is a flexible model that we can use for designing single patterns, complex patterns, or multi patterns also…. Therefore, this paper will in this context provide FWM and FDTD (Finite Difference Time Domain) method for surveying this model.
Downloads: 0
References
A. Taflove and S. C. Hagness, Computational Electrodynamics: The Finite-Difference Time-Domain Method, Artech House, 2000.
Constantine A. Balanis, Antenna Theory Analysis and Design, John Willey & Sons, 1997.
Gonca Cakir, Levent Sevgi, Design, Simulation and Tests of a Low-cost Microstrip Patch Antenna Arrays for the Wireless Communication, Turk J Elec Engin, Vol.13, No.1 2005.
K.R. Rao and P.C. Yip, David Hall and James Llinas, Lal Chand Godara, Robert Crane, Guarav Sharma, Yu Hen Hu and JengNeng Hwang, Antonia PapandreouSuppappola, Gillian Davis, Vyacheslav Tuzlukov, Nikolaos Uzunoglu and Konstantina S. Nikita, Handbook of Antennas in Wireless Communications, CRC Press LLC, 2002.
Nguyễn Hữu Phương, Xử Lý Tín Hiệu Số, Nxb.Thống Kê, 2003.
Nguyễn Phùng Quang, Matlab & Simulink Dành Cho Kỹ Sư Điều Khiển Tự Động, Nxb.Khoa Học và Kỹ Thuật, Hà Nội, 2005.
R.Garg, P. Bhartia, I. Bahl & A. Ittipiboon, Microstrip Antenna Design Handbook, Artech House, Boston. London, 2001.
Website: http://www.FDTD.org
Yee, K. S., “Numerical Solution of Initial Boundary Value Problems Involving Maxwell’s Equations in Isotropic Media,” IEEE Trans. Antenna and Propagation, Vol. 14, 1966, pp. 302-307.
