Carrier PWM control of cascade multilevel inverter for three-phase four-wire shunt active filter
Corressponding author's email:
tapchikhgkdt@hcmute.edu.vnKeywords:
PWM, NPC multilevel inverter, 5-level cascade inverter, PWM algorithmAbstract
Cascade multilevel inverters are known as perspective converters for applications. They can help to use simple integrated power modulus, simplify and avoid the problem of DC source balancing. The paper introduces a new carrier PWM technique to control the cascade inverter output. Improving electrical power quality by reducing harmonic content caused by nonlinear load will be considered. In this paper, there will be mathematically formulated and simulated for 5-level cascade inverter and applied in filtering harmonics in three-phase four-wire unbalanced load system.
Downloads: 0
References
A. Bendre, G.Venkataramanan, V. Srinivasan, D. Rosene, “Modeling and design of a neutral point voltage regulator for a three-level diode-clamped inverter using multiple carrier modulation,” EPE 2003 Conference, CD-ROM Proceedings.
Chen-Che Chen and Yuan-Yih Hsu, “A Novel Approach to the Design of a Shunt Active Filter for an Unbalanced Three- Phase Four-Wire System under Condition Nonsinusoidal.” IEEE Transactions on Power Electronics. Vol.15, No.4, October 2000.
D.G. Holmes, T.A. Lipo, “Modern Pulse Width Modulation Techniques for Power Converter”, IEEE Press, 2003.
Emílio F. Couto, Júlio S. Martins, João L. Afonso, “Simulation Results of a Shunt Active Power Filter with Control Based on p-q Theory.” IEEE Transactions on Power Electronics, 2003.
J. Rodríguez, J.S. Lai, and F.Z. Peng, “Multilevel Inverters: A Survey of Topologies, Controls, and Applications,” IEEE Transactions on Industrial Electronics, Vol.49, No.4, August 2002, pp.724-739.
N.V. Nho, N.X. Bac, “CarQArier PWM Control of Cascade Hybrid NPC 3-Level Inverter and Two-Level Inverters,” 2007.
Patrick H. Edson Watanabe, “New Control Algorithms for Series and Shunt Three- phase Four-Wire Active Power Filter.” IEEE Transactions on Power Delivery. Vol.10, No.3, July 1998.
Y.H. Lee, R.Y. Kim, D.S. Hyun, “A novel SVPWM strategy considering DC-link balancing for a multi-level voltage source inverter,” APEC 99, Vol.1, pp.509 – 514.
